Housing material | Stainless steel, painted steel | |
Colour | Silver matt, black moire | |
Dimensions without arms | 270×768×1090 mm | |
Dimensions with arms | 770×768×1090 mm | |
Width of the blocked passage | 770 mm | |
Passage width min/max | 500 mm / 560 mm | |
Net weight | 67 kg | |
Arms are available | Yes | |
Anti-panic system | Removal barrier by automatic transfer to an open state | |
Throughput capacity | 30 people per minute | |
Supply voltage (Direct) | 12 V DC | |
Current consumption, max. | 2 A | |
Power consumption, max. | 3 W in standby mode, 24 W when the passage is blocked | |
Interfaces | Wiegand 26, Wiegand 34, Wi-Fi and RS-485 | |
Number of readers | 2 (for turnstiles with readers) | |
Access card format | Mifare 1K + EM Marine | |
Software included in the scope of supply | Yes | |
Integration with the Physical Access Control System (PACS) | With any Physical Access Control System | |
Offline mode is available | Yes | |
Number of users | In autonomous module mode or autonomous checkpoint mode without memory expansion module – 1,500. More than 1,500 with memory expansion module (sold separately) | |
Number of events | up to 4,000 (additional module is required | it is sold separately) |
Operating temperature | From +1 °C to +40 °C | |
Operating humidity | Not higher than 80% | |
Protection class/Installation location | IP41/indoors | |
Time before failure (medium) | Not less than 2 million cycles | |
Average service life | Not less than 8 years | |
Power supply | Sold separately | |
Remote | Wired remote with push-buttons is included in the scope of supply. Optional Wi-Fi remote is sold separately. Wi-Fi control is available from an Android device | |
