Quick Line QL-04 turnstile

Description;Value

Dimensions, side unit with open flap (Height*Width*Depth);1050*1330*208 mm Dimensions, the central element of the turnstile with open flap (Height*Width*Depth);1050*1330*208 mm Dimensions, side unit depending on the width of the passage 660 mm (Height*Width*Depth);1050*1330*510 mm Dimensions, side unit depending on the width of the passage 900 mm (Height*Width*Depth);1050*1330*630 mm Dimensions, the central element of the turnstile depending on the width of the passage 660 mm (Height*Width*Depth);1050*1330*812 mm Dimensions, the central element of the turnstile depending on the width of the passage 900 mm (Height*Width*Depth);1050*1330*1052 mm Weight, 660 mm side unit;110 kg Weight, 900 mm side unit;113 kg Weight, 660 mm central unit;130 kg Weight, 900 mm central unit;138 kg Temperature range(operation, transportation and storage);+1...+40 °С Atmosphere relative humidity;80% Throughput;30 persons / min Throughput in the free passage mode;60 persons / min Cycles to failure;4 500 000 passes Card standart;Mifare/EM-Marine* Capacious card container*;>150 pcs Max. number of connected remote control panels;2 pcs Lifetime;8 year Power consumption (side, central module);120, 240 W Power voltage (nominal);12 V Power voltage (working);10,8...13,2 V Average current in standby mode**;0,7 A Average current in operational mode**;5,0 A Maximum current consumption (when arms are folded during “anti-panic” mode)**;7,5 A

Denomination;Quantity

QL-04 Turnstile column;1 pcs Card reader (Mifare/EM-Marine)**;2 pcs Card Collector**;1 pcs RC Panel Praktika;1 pcs Keys to the locks of the card collector container (if available);4 pcs Approval sheet;1 pcs Installation guidelines;1 pcs Installation guidelines and Operational manual;1 pcs Maintenanse operations;1 pcs Datasheet;1 pcs Half height barriers*;1 pcs ScrewМ10х60 DIN933 *;8 pcs Anchor type SORMAT ES10 *;8 pcs Allen key S17*;1 pcs
