Quick Line QL-05 turnstile

Description;Value

Side unit with open flap, dimensions (Height*Width*Depth);1140*1320*208 mm The central element of the turnstile with open flap, dimensions (Height*Width*Depth);1140*1320*208 mm Side unit depending on the width of the passage 660 mm, dimensions (Height*Width*Depth);1140*1320*510 mm Side unit depending on the width of the passage 900 mm, dimensions (Height*Width*Depth);1140*1320*630 mm The central element of the turnstile depending on the width of the passage 660 mm, dimensions (Height*Width*Depth);1140*1320*812 mm The central element of the turnstile depending on the width of the passage 900 mm, dimensions (Height*Width*Depth);1140*1320*1052 mm Side unit depending on the width of the passage 660 mm, Weight;90 kg Side unit depending on the width of the passage 900 mm, Weight;93 kg The central element of the turnstile depending on the width of the passage 660 mm, Weight;106 kg The central element of the turnstile depending on the width of the passage 900 mm, Weight;112 kg Temperature range(operation, transportation and storage);+1...+40 °С Atmosphere relative humidity;80% Throughput;30 persons/min Throughput in the free passage mode;60 persons / min Cycles to failure;4 500 000 passes Capacious card container*;>50 pcs Max. number of connected remote control panels;2 pcs Lifetime;8 year Power voltage (nominal);12 V Power voltage (working);10,8...13,2 V Power consumption (side, central module);120, 240 W Maximum current consumption (when arms are folded during “anti-panic” mode)**;7,5 A

Denomination;Quantity

OXGARD QL-05 Turnstile column;1 pcs RC Panel Praktika;1 pcs Keys to the locks of the card collector container (if available);4 pcs Approval sheet;1 pcs Installation guidelines;1 pcs Installation guidelines and Operational manual;1 pcs Maintenanse operations;1 pcs Datasheet;1 pcs Half height barriers**
