Description;Value
Panel type;Multi-apartment
Display;10“ TFT, colour, with backlight and heated
Camera;1/3”
Angle;90° horizontal × 56° vertical
Resolution;1.3 Мp
Output video;HD (1280×720), H.264 Main Profile
Night backlight;6 LEDs
Light sensitivity;0.01 Lux
Protection class;IP65
Working temperature;-40 – +65 °С
Operating humidity;0% – 86%
Storage Humidity;0% – 60%
Power consumption;6.5 W, in standby – 3.6 W
Power supply;+12 V DC (+8% -4%)
Case;Aluminum
Colours;Silver, Black, Gold
Dimensions of the panel;180×400×46 mm
Dimensions for installation;172×378×58 mm
Installation;Flush mount
Keyboard;Touch Screen
Interface;Multi-language, WEB-interface
Access control;UKEY (EM-Marin/ MIFARE®/NFC/Bluetooth)
Identifiers in the panel memory;20 000
Face recognition identifications;10 000 faces
Integration with ACS;Output WIEGAND-26, 32, 34, 37, 40, 42, 56, 58, 64 bit
Supported Wiegand types;26, 32, 34, 37, 40, 42, 56, 58, 64
Authentication;Separate password allowing access to the settings for the WEB-interface
Talking mode;Duplex
Additionally;Software Link support, SIP P2P, Built-in relay, Proximity sensor, Open API
Lock opening;By means of a monitor, a code, an access card, the BAS-IP Intercom application, the BAS-IP UKEY application, Face Recognition, Identification
