Motorized two-arm T2-M-SF turnstile
Compact motorized two-arm turnstile with automatic anti-panic arms included set provides access control for enterprises and organizations and automatically makes the passage free in emergency situations. Ready-to-use access control solution with RFID readers, controller, memory for 1500 cards and automatic function of anti-panic arms. Mobile application for configuration and monitoring, open API for integration.
Get Price
Turnkey access control solution for educational institutions based on motorized two-arm turnstile
Free Android App
Upload firmware for turnstile upgrade
Configure and control the turnstile in checkpoint mode
Control the turnstile in 6-button remote mode.
Execution options
T2-M-SF v.1
A model with a starting set of all necessary functions.
Remote control or integration with external controllers is provided.
T2-M-SF v.1.1 - turnstile with counter
Starting model is equipped with hardware and software features for online recording of the event log (in-out). Event log is generated by the dates and direction of passage in separate files on a working computer on an Ethernet network.
Autonomous memory module for 4000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".
Free software (provided individually) allows data exchange between the 4,000-event unit and the workstation via Ethernet network and online recording of the event log (in-out).
Starting model is equipped with hardware and software features for online recording of the event log (in-out). Event log is generated by the dates and direction of passage in separate files on a working computer on an Ethernet network.
Autonomous memory module for 4000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".
Free software (provided individually) allows data exchange between the 4,000-event unit and the workstation via Ethernet network and online recording of the event log (in-out).
T2-M-SF v.1.1 - stop COVID counter
The basic model without readers is supplemented with a standalone hardware and software ability to count passages and monitor the number of people indoors. The turnstile will automatically block the entrance when the number of people indoors reaches the set limit. Implemented 2 schemes of work:
Single turnstile T2-M-SF (BF) v.1.2;
Master turnstile T2-M-SF (BF) v.1.2 and synchronous connection of up to 3 additional turnstiles T2-M-SF (BF) v.1 for collaboration.
The counter module is used to record quantitative data and synchronize turnstiles. The Android application MaterCard is used for configuration. The Android application Visitor Counter is used for monitoring STOP-COVID solution.
The basic model without readers is supplemented with a standalone hardware and software ability to count passages and monitor the number of people indoors. The turnstile will automatically block the entrance when the number of people indoors reaches the set limit. Implemented 2 schemes of work:
Single turnstile T2-M-SF (BF) v.1.2;
Master turnstile T2-M-SF (BF) v.1.2 and synchronous connection of up to 3 additional turnstiles T2-M-SF (BF) v.1 for collaboration.
The counter module is used to record quantitative data and synchronize turnstiles. The Android application MaterCard is used for configuration. The Android application Visitor Counter is used for monitoring STOP-COVID solution.
T2-M-SF v.2 - autonomous module
Basic model with readers allows offline access control mode for up to 1,500 users. Flexible tools for entering users into the turnstile memory are provided.
Built-in readers for access cards of two E-Marine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users uses a set of features of the company's ANDROID App "Master Card".
Basic model with readers allows offline access control mode for up to 1,500 users. Flexible tools for entering users into the turnstile memory are provided.
Built-in readers for access cards of two E-Marine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users uses a set of features of the company's ANDROID App "Master Card".
T2-M-SF v.2.1 - autonomous checkpoint
Basic model with readers allows offline access control mode for up to 1,500 users, as well as keeping of a log of up to 4,000 events using key tags (user ID, event date and time, direction of passage, etc.), that can be downloaded through an Android device. Also, based on an individual project, the event log can be downloaded in the form of separate files to a working computer via Ethernet network using free software.
Built-in readers for access cards of two EMarine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users.
Autonomous memory module for 4,000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".
Basic model with readers allows offline access control mode for up to 1,500 users, as well as keeping of a log of up to 4,000 events using key tags (user ID, event date and time, direction of passage, etc.), that can be downloaded through an Android device. Also, based on an individual project, the event log can be downloaded in the form of separate files to a working computer via Ethernet network using free software.
Built-in readers for access cards of two EMarine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users.
Autonomous memory module for 4,000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".
Specification
| Description | Value |
|---|---|
| Housing material | Painted in dark-gray and gray colors steel |
| Dimensions with arms | 780×786×960 mm |
| Width passage | 477 mm |
| Weight net | 30,5 kg |
| Through-put capacity | 30 pers/min |
| Power voltage | 12 V |
| Input current, max. | 2 А |
| Interfaces | Wiegand 26, Wiegand 34, Wi-Fi and RS-485 |
| Operating temperature and humidity | From +1°C to +40°C, not higher than 80% |
| Nonfailure operating time | Not less than 2 mln. cycles |
| Average lifetime | Not less than 8 years |
