Big Foot tripod massive series

All the advantages of the SF series, plus:Ideal solution for large flows. Passage width up to 800 mm. Easy-to-assemble structure - three modules.Modular construction allows delivery savings.

Anti-panic arms are included. RC plate is included. Fail safe principle of the operation. Integration with 3rd party equipment. Custom led indication. Wi-fi turnstile control. Opened API for integration.

Get Price

We will send the price list today. By clicking on the button, you consent to the processing of personal data and agree to the privacy policy.
Out of the box solution for a check-point in factories with expanded aisle width

Free Android App

Upload firmware for turnstile upgrade

Configure and control the turnstile in checkpoint mode

Control the turnstile in 6-button remote mode.

Downloads

Execution options


T3-NO-BF v.1

A model with a starting set of all necessary functions.
Remote control or integration with external controllers is provided.

T3-NO-BF v.1.1 - turnstile with counter
Starting model is equipped with hardware and software features for online recording of the event log (in-out). Event log is generated by the dates and direction of passage in separate files on a working computer on an Ethernet network.
Autonomous memory module for 4000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".
Free software (provided individually) allows data exchange between the 4,000-event unit and the workstation via Ethernet network and online recording of the event log (in-out).

T3-NO-BF v.1.1 - stop COVID counter
The basic model without readers is supplemented with a standalone hardware and software ability to count passages and monitor the number of people indoors. The turnstile will automatically block the entrance when the number of people indoors reaches the set limit. Implemented 2 schemes of work:
Single turnstile T3-NO-SF (BF) v.1.2;
Master turnstile T3-NO-SF (BF) v.1.2 and synchronous connection of up to 3 additional turnstiles T3-NO-SF (BF) v.1 for collaboration.
The counter module is used to record quantitative data and synchronize turnstiles. The Android application MaterCard is used for configuration. The Android application Visitor Counter is used for monitoring STOP-COVID solution.


T3-NO-BF v.2 - autonomous module
Basic model with readers allows offline access control mode for up to 1,500 users. Flexible tools for entering users into the turnstile memory are provided.
Built-in readers for access cards of two E-Marine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users uses a set of features of the company's ANDROID App "Master Card".

T3-NO-BF v.2.1 - autonomous checkpoint
Basic model with readers allows offline access control mode for up to 1,500 users, as well as keeping of a log of up to 4,000 events using key tags (user ID, event date and time, direction of passage, etc.), that can be downloaded through an Android device. Also, based on an individual project, the event log can be downloaded in the form of separate files to a working computer via Ethernet network using free software.
Built-in readers for access cards of two EMarine or Mifare standards are combined with colour indicators of passage.
Built-in autonomous memory for 1,500 users.
Autonomous memory module for 4,000 events for monitoring and recording personnel access using a set of features of the company's ANDROID App "Master Card".

Specification
